📈 Key Features
5 × Gigabit RJ‑45 Ports (10/100/1000 Mbps): High‑speed wired connections for PCs, NAS, IP cameras, printers, and more.
Unmanaged & Plug‑and‑Play: No setup or management interface required — just plug and use.
High Switching Capacity: Up to 10 Gbps backplane bandwidth for smooth data flow.
Forwarding Rate: Approximately 7.44 Mpps for efficient packet handling.
Auto‑MDI/MDIX Support: Automatic cable detection and adjustment for easy installation.
Sturdy Metal Housing: Durable metal case with enhanced heat dissipation and silent, fanless operation.
Cloud Visibility: Can be visible and monitored via the Ruijie Cloud app when integrated with compatible ecosystem devices.
Energy Efficient: Low power consumption (≤ 5 W typical).
Surge Protection (some versions): Up to 6 kV protection on ports to help prevent damage from electrical surges.
| Specification | Details |
|---|---|
| Model | RG‑ES105GD |
| Switch Type | Unmanaged, No PoE |
| Ports | 5 × 10/100/1000 Mbps RJ‑45 |
| Switching Capacity | 10 Gbps |
| Forwarding Rate | ~7.44 Mpps |
| MAC Address Table | 2,000 entries |
| Auto‑MDI/MDIX | Yes |
| Housing | Metal, Fanless |
| LED Indicators | Link/Act per port + Power |
| Power Supply | External DC 5 V/1 A |
| Power Consumption | ≤ 5 W |
| Operating Temp. | 0 °C → 40 °C |
| Storage Temp. | –40 °C → 70 °C |
| Dimensions | ~119 × 75 × 24 mm |
| Weight | ~0.15 kg (net) / 0.25 kg (gross) |
| Warranty | ~3 years (varies by region) |
🎯 Best Use Cases
✅ Home Networks – Add multiple wired connections for computers and entertainment devices.
✅ Small Office & SOHO – Reliable gigabit connectivity for workstations, printers, and file servers.
✅ Surveillance / CCTV Networks – Connect multiple IP cameras with stable wired performance.
✅ Silent Environments – Fanless design makes it ideal for noise‑sensitive spaces.
